MONOMIX

The solventless monocomponent adhesive dispenser

MONOMIX is the solventless monocomponent adhesive dispenser that Remac has designed to make your coupling process more efficient and fast.

MONOMIX has a structure that allows you to always have 2 drums of adhesive at temperature ready for use. You can change the drums in a simple and fast way, without interrupting the production, thanks to a pneumatic system that lifts the pumping group and a mechanical arm that rotates it to center it on the spare drum. Moreover, you can check at any time the level and temperature of the adhesive, to avoid errors and malfunctions.

MAIN FEATURES:

• Power supply: 400+N volt
• Pneumatic supply: 8 bar
• Pneumatic suction pump: 1 inch
• Maximum temperature: 90 °C
• Maximum flow rate (at working temperature): 3-5 kg/min.
• Drums usable: 220 kg standard
• Heated dosing pump



• Control panel for setting working temperatures
• Sonar for adhesive level control
• Heated base for drum support
• Support and movement arm for dosing pump
• Dimensions: 1400x800xH. 1800
• Frame mounted on swivel wheels
• Electrical panel on board machine with easy-to-use instrumentation
